See also: CaptionAnchorHoriz, Caption, CaptionTrim, CaptionPosX, CaptionPosY, CaptionAlignment

CaptionAnchorVert


Unit: SDL_rchart
Class: TContourPlot
Declaration: property CaptionAnchorVert: TCaptionAnchorVert;

The property CaptionAnchorVert specifies the vertical position of the caption anchor. It may assume one of the following values:

Value Reference position
cavControlTop top border of the control
cavChartTop top border of the chart
cavChartCenter middle of the chart
cavChartBottom bottom border of the chart
cavControlBottom bottom border of the control

The following figure shows the caption anchored to the top of the control.
